Name: 120W Laser Beam Light With LED Strip
Availability: InStock

Leave A Message

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.

120W Laser Beam Light With LED Strip

120W Laser Beam Light delivers an ultra-powerful 2.5° narrow beam through a 160mm lens,offering strong penetration and impact for outdoor stages and events.

Brand model :
QR-LS120
Input voltage :
AC100V-240V, 50/60Hz
Light source :
100W Laser module + auxiliary LEDs
Color wheel :
14+1/Super cool rainbow effect
Product size :
33.5*24*56cm(L*W*H)
Net weight :
13.5kg
Protection level :
IP20
Channel mode :
18 CH

Inquiry Now

Function Description

120W Laser Beam Light With LED Strip features a high-efficiency 100W laser module combined with an LED auxiliary system.With a 2.5° ultra-narrow beam angle and a 160mm large-diameter front lens,it delivers a highly concentrated,powerful beam with excellent penetration and visual impact.The fixture is built with a flame-retardant,high-temperature-resistant nylon housing,making it ideal for outdoor stage productions,entertainment venues,and a wide range of commercial lighting applications.

Technical parameters

Light Source System

Light source: 100W Laser module + auxiliary LEDs
Light source life: >20,000 hours

Optical System

Beam angle: 2.5°
Front lens diameter: 160 mm

Color System

1 independent color wheel with 14 colors + open, featuring stepping and linear color change, allowing split color effects
Super cool rainbow effect

Gobo system

Fixed gobo wheel: 13 fixed gobos+white, which can change speed and shake

Effect

Prism: 8 facet prisms and 8+16 facet prisms, can rotate independently in both directions
Dimming: 0–100% linear dimming
Strobe: Multiple-speed electronic strobe effects
Frost: 1 independent frost , 0-100% frost, natural and soft light spot

Pan&Tilt

Pan/Tilt Movement:540°/270°
Automatically return to its original position and perform 16-bit precision fine-tuning

Electrical and Interface

Input voltage: AC 100–240V, 50/60Hz
Rated power: 400W
Signal connections: 3-pin XLR input/output

Control and Programming

Control channels: 18 CH
Control protocol: standard DMX512/RDM protocol
Display mode: 1.8 LCD touch screen, Chinese-English bilingual operating system, can reverse 180° display
Energy saving sleep: automatically enters the sleep state when the signal is disconnected, which is safe and energy saving
Software upgrade: software can be upgraded via DMX signal cable
Heat dissipation system: high-efficiency heat dissipation system, intelligent speed-regulating fan, built-in temperature sensor, and automatic adjustment of the heat dissipation system

Fixture Structure

Product appearance: nylon flame-retardant, heat-resistant
Working environment: -20 °C to 40 °C
Protection level: IP20

Size and weight

Product dimensions: 33.5×24×56cm (L×W×H)
Net weight: 13.5 kg
